A drawer full of loose batteries and no idea which ones still have life in them? A battery tester answers that in seconds. The BT-168 is a simple analog tester that needs no batteries of its own, and it reads almost every common cell. Here is how to use one and how to read the result properly.
Why a load tester beats a multimeter
A multimeter shows voltage with no load, which can make a tired battery look healthy. A tester like the BT-168 checks the cell under a small load, which is much closer to how your device actually draws power. That is why a battery can read close to its rated voltage yet still fail in use.
What the BT-168 can test
- AA and AAA cells
- C and D cells
- 9V (PP3) batteries
- 1.5V button and coin cells
It covers both 1.5V cells and 9V batteries, which is most of what a typical home uses.
How to test a battery, step by step
- For AA, AAA, C or D, slide the sprung arm open and seat the battery in the cradle, matching plus and minus to the markings.
- For a 9V or a button cell, use the fixed contacts at the end of the tester marked for that type.
- Hold the battery in contact for a second and read the needle on the scale.
- Note the zone the needle lands in, then remove the battery.
How to read the result
- Green or GOOD zone: the battery is healthy, put it back in service.
- Yellow or LOW zone: usable for low-drain devices like clocks or remotes, but on its way out.
- Red or REPLACE zone: the battery is spent, recycle it.
One tip: test under the type that matches the battery, since a 9V and a 1.5V cell use different parts of the scale.
When should you replace rather than test?
For smoke alarms and other safety devices, replace on a schedule rather than waiting for a low reading. For everyday gadgets, testing saves you from binning batteries that still have plenty left, and from trusting ones that do not. If a device feels sluggish, a quick test usually tells you whether the battery or the device is at fault.
Which battery did your device take again?
If you are testing a pile of mixed cells, our guides make it easy to match the right replacement. See which battery your device uses for household devices, the coin cell guide for CR2032 and friends, and the button battery cross-reference for those tiny LR and AG codes.
Quick FAQ
Does the BT-168 need its own battery? No. It draws a tiny amount of power from the battery being tested, so there is nothing to charge or replace.
Can it test lithium coin cells like CR2032? It is designed for 1.5V button cells. A 3V coin cell reads differently, so treat the result as a rough guide rather than an exact figure for those.
Can it test rechargeable AA and AAA? Yes, though NiMH rechargeables rest at about 1.2V, so a healthy rechargeable reads a little lower than a fresh alkaline. Judge it against that lower baseline.
